Understanding R36S / ArkOS boot sequence[edit]

The standard boot sequence (shown here) of a R36S is completely customizable.

Boot Logo
Plymouth Theme
EmulationStation loading screen

Bootlogo and Loading Screen Mega Pack[edit]

Download link #1: https://www.mediafire.com/file/n98y9q9rux2t7wf/R36S_Bootlogo_and_loading_screens_pack_october_2024.zip/file

344 .bmp files
41 .gif files
9 .ascii files

Download link #2 (mp4 loading screens): https://www.mediafire.com/file/x890zdpyo9pp7fc/R36S+mp4+loading+screens.zip/file

41 .mp4 files

Download link #3 (gif loading screens): https://www.mediafire.com/file/zhi9xmgs5ihctu9/80+loading+gifs+november+10+2024.zip/file

80 .gif files

All files are in 4:3 aspect ratio, 640x480 or 1024x768 resolution and should work fine for similar handheld devices. Gif files can be downloaded individually below.

Guide[edit]

This is for the ArkOS firmware.

Loading images[edit]

Loading images (.jpg, .gif, .mp4, .ascii) are located on the EASYROMS partition (easyroms/launchimages/loading.*). You need to rename the animated gifs or mp4 videos to loading.gif/mp4. If you want to use a normal image you could save the .bmp files as a .jpg file with paint for example, and replace the loading.jpg in the launchimages folder.

Use this option to enable animated loading screens (.gif or .mp4)
Use this option to enable animated loading screens (.gif or .mp4)
ArkOS UI settings
Choose between a normal picture, ascii or disable loading screens

Boot logos[edit]

Rename the bmp image to logo.bmp and put it in the BOOT partition. It's possible to cycle through different images if you put multiple bmp files in the BMPs folder.

Boot logos can be created easily. Just use any image in 4:3 format with 640x480 and save it as a 24bit BMP file with Paint. You can use ezgif.com for easy cropping or resizing.

Boot videos[edit]

Rename the mp4 video to logo.mp4 and put it in the BOOT partition. You may have to delete the other bootlogos on the SD card. This is only supported by the ArkOS Community Maintained Image.

Plymouth Theme Creator[edit]

Small script to create your own Plymouth themes from a GIF.
It is also possible to adjust the GIF speed (7 modes, from very slow to very fast).

Link: https://github.com/Jason3x/Plymouth-Theme-Creator

Plymouth Theme + EmulationStation logo[edit]

It's possible to change the "Plymouth theme" and the EmulationStation logo during boot. Phafael has made a guide on his GitHub account:

https://github.com/phaf36s/r3xs-arkxp

Plymouth Theme Selector[edit]

ArkOS standard plymouth theme

Reddit thread / guide: https://www.reddit.com/r/R36S/comments/1gnri3v/plymouth_theme_selector/

Download: https://drive.google.com/file/d/1SR_N3XlwQMJTkAR9RnmhG-ZfZOk_3vwq/view?usp=sharing

Here is a nice explanation by Constant-Might521 about the boot process and Plymouth themes.

Change Bootlogo on AmberELEC[edit]

Changing bootlogos and loading screens is not supported on AmberELEC. You can only change the EmulationStation loading screen.

to change the logo after the splash screen you will have to connect your console in ssh and go to: storage/.config/emulationstation/resources. The file is logo.png and is 640x480 in size

Source: reddit

Change Bootlogo on PAN4ELEC[edit]

Customizable ANIMATED BOOT SPLASH. 640x480 MP4s, GIFs, JPG/PNG single image or image sequence. multiple mp4 files will trigger random selection for boot and shutdown. place videos or image files in /storage/.config/splash/usr_logo. videos override images. if using video do remember to convert them using Handbrake to 640x480, and quality between 23-26.
